Optical measurement data recording for the best quality

No time lost thanks to a virtual measurement space for automated scanning

Once the order has been placed and the CAD data has been sent, we immediately start work on the programming and parametric reporting, which means that the 3D measurement of the pieces can start as soon as the materials arrive.


GOM-certified German 3D measurement service provider

As a certified GOM service provider, we rely on the quality of the ATOS Q series, which has a long-standing track record. Contactless and non-destructive measurement methods are not only used in industrial series and prototype production, but increasingly also in the field of additive manufacturing in the form of initial sample test reports (ISTR) or quality control.

Measurement technology service provider for 3D printing I additive manufacturing

We measure, check, inspect and evaluate 3D-printed pieces. We do this by recording highly precise geometric data, including complex structure or free-form surfaces, using optical measuring techniques. Based on a resolution of several million points, we document informative measurement results in your own test report. The detailed quality information is provided in parametric form using a variety of inspection methods, such as form and positioning tolerances, cross-section analyses, distance checks and more.

Your reliable 3D measurement service

For an initial quality assessment, we recommend a target/actual comparison with false-colour rendering. Even the smallest details are very important to us, whether it’s in quality assurance, production, or research and development. Our engineers always provide a suitable and comprehensible analysis of the 3D scan data we record.

Our range of 3D measurement services

Precise and high-resolution

We always have the right solution for you:


✓ measurement path programming including collision checks

✓ object-specific digitisation

✓ evaluation of specified test characteristics

✓ individual piece measurement for incoming/outgoing goods checks

✓ digitisation and evaluation of small unit volumes



Benefits of semi-automated measurements:

✓ saves time thanks to scan preparation using box dimensions

✓ short preparation times

✓ 3D models with the best detail reproduction

✓ individual measurement reports

✓ numerous analysis functions

✓ possible without CAD data or recorded measurements

Fast and cost-effective

Series measurement up to 100% tests


✓ measurement path programming including collision checks

✓ programming on the basis of inspection characteristics

✓ parametric evaluation of test characteristics

✓ trend analyses to determine when action is required

✓ initial sample test reports according to drawing

✓ quality assurance during ongoing projects

✓ CAD data and recorded measurements required


Benefits of fully automated series measurement:

✓ saves time thanks to virtual project preparation

✓ short throughput times with utmost precision

✓ complete piece analyses

✓ individual, parametric measurement report

✓ automated and fully reproducible

✓ multiple loading supported



Saving time and resources

We work in parallel for you


✓ program creation for automated GOM measurement systems

✓ offline programming of robot paths and inspection tasks

✓ creation of customised, parametric measurement reports including company logo

✓ consideration of current standards

✓ use of the latest software

✓ the sharing of a current VMR and the measurement equipment used is a prerequisite


Benefits of program creation in the GOM VMR:

✓ on-demand access

✓ predictable project costs

✓ flexibility and improved competitiveness

✓ bridging capacity bottlenecks

✓ compensating for personnel absences


3D measurement report based on client template

Create your own customised 3D measurement report:


✓ inspection cross-section

✓ false-colour comparison

✓ angle, distance and diameter measurement

✓ parallelism, perpendicularity, evenness

✓ straightness, cylindricity, roundness

✓ surface defect representation

✓ trend analysis diagrams


... and much more!


Benefits of 3D measurement technology measurement reports:

✓ customised measurement reports with your company’s own design

✓ deviations immediately apparent thanks to being highlighted in red, amber or green

✓ PDF and CSV export

Precise measurements in the measurement space

We always work with the latest technologies:


GOM ScanCobot:

✓ collaborative robot

✓ motorised turntable

✓ blue light equaliser

✓ high-speed band projection

✓ ATOS Q 8M

✓ measurement field 270

✓ max. piece size 500x500x1000mm³

✓ max. piece weight 50kg


Memmert Hpp260eco:

 ✓ constant climate chamber

 ✓ Temperature range: 0°C-70°C

 ✓ Humidity range: 10%-90%

 ✓ Capacity: 256 litres

 ✓ high-precision regulation

 ✓ around 90% more energy-efficient than compressor-cooled devices

 ✓ integrated documentation of temperature and humidity

Do the parameter settings really improve the quality of the plastic parts?

Yes. Different parameter configurations still have a significant influence on the quality of pieces produced using additive methods. In the following, we show you how you can optimise the quality of your 3D prints and check your settings:


You can improve dimensional accuracy by

  • Adjusting the parameter settings for better piece quality
    • scaling pieces
    • changing the shell/core values
    • taking shrinkage into consideration

           (system-dependent parameters)


    • adjusting the thickness of the first layer
    • setting the extrusion multiplier
    • changing the extrusion width
    • setting the horizontal size compensation
    • adjusting the production space temperature
    • correcting the overlap
    • changing the beam offset
    • setting the laser beam output

     Taking into account external factors such as


    • room temperature and air humidity
    • cleanliness in the additive manufacturing process
    • storage of materials
    • switching batches

    Start multiple quality production jobs using a suitable reference piece and use optical measurement technology to


    • create a measurement basis for comparisons
    • verify your parameter settings at any time using the basis for comparison
    • be able to make subsequent adjustments at regular intervals
    • regulate changes following long production times

    We are happy to help you with the 3D digitisation and evaluation of your measurement series.

Does a measurement concept with standardised framework conditions make sense for pieces produced using additive methods?

When it comes to additive series production in particular, compliance with defined (environmental) conditions with respect to temperature and air humidity is very important for the comparability of test results. In the following, we show you what standardised framework conditions make particular sense for 3D printing, as well as the benefits of a measurement concept:

  • Standardized framework conditions in metrology
    • room temperature generally refers to a wide range of temperatures that can be anywhere from 18°C to 28°C
    • if tests are to be conducted in a standardised climate, this refers to specific conditions that are set out in ISO 291 / ASTM D 618. In accordance with those standards, here in Germany, 3D-printed test bodies are stored for at least 16 hours at 23 ± 2°C, 50 ± 10% relative humidity before they can be digitised
    • tests can also be conducted at high or low temperatures, for which different requirements can be specified

    There are also specific material properties in the field of 3D printing:


    • the thermal expansion coefficient of many plastics is 20 times higher than for most metals
    • polyamides swell as a result of the absorption of moisture

    The benefits of a measurement concept with standardised framework conditions in the field of additive manufacturing:


    • complaints are avoided
    • customer satisfaction is enhanced

    It is our pleasure to offer you and your customers the security of providing dimensional accuracy within the framework conditions, even for challenging measurements. With our climate chamber, we keep the conditions for your measurement series constant at the desired temperature and humidity.

Today, tomorrow, or this morning

Ask us about our collection and delivery service in the Calw, Böblingen, Enzkreis and Pforzheim municipalities.
